PA66 GF25 Nylon Polyamide Extruder Machine Single Screw For Thermal Barrier Tape

  • 1
  • 2
  • 3

Brand Name : Polywell

Model Number : PW-60/70/80

Place of Origin : China

MOQ : 1 Set

Price : USD 15,000- 20,000 Per Set

Payment Terms : T/T, Western Union, MoneyGram

Delivery Time : 30-38 Working Days

Packaging Details : Wooden case

Supply Ability : 20 Sets per Month

Application : Plastic Granules

Warranty : 12 Months

Weight : About 1 Ton

Name : Plastic Extruding Machine

Screw design : Single-screw

Condition : New

Automatic grade : Automatic

Plastic processed : PA

Contact Now

PA66GF25 Polyamide Extruder Machine Single Screw For Thermal Barrier Tape

Product Introduction:

What is extruder in polymer processing?

Plastic extrusion is a continuous high volume manufacturing process in which a thermoplastic material is homogeneously melted and then forced out of the shaping die by means of pressure. There are different types of an extruder.

The extruder we sell is single screw extruder for the production of PA thermal barrier profiles.


Processing Technique:
Nylon material → drying → heating → extrusion → stereotype → finished product

PA66 GF25 Nylon Polyamide Extruder Machine Single Screw For Thermal Barrier Tape

Parameters of Single Screw Reactive Extruder

Production Speed Around 8-12cm/min
Strip Shape All kinds of shape
Raw Material PA6.6 granules reinforced by 25% glass fiber
Cooling Water Cooling
Usage Produce thermal break strip
Type Plastic extrusion machine
Winding Machine Available
Cutting Machine Available
Worktable Available



PA66GF25 Polyamide Profiles Extrusion Machine Including:

  • Automatic feeding machine

  • Hopper dryer

  • Main PA strip extrusion machine

  • Molds/Tools/Dies

  • Cutting machine

  • Fixture device

  • Cutting machine

  • Worktable

  • Winding machine


Machine Characteristic:

1. The barrel is heated by stainless steel heater, withstand voltage 400V

2. The professional dryer makes raw material convection with hot air uniformly, and the drying uniformity is good. Its thermal insulation structure prevents heat dissipation and promotes energy saving.

3. Special new screw make sure the machine has low energy consumption, good plasticizing ability and stable extrusion flow.

4. The extruder uses high-quality carbide twin-screws to ensure high plasticization of PA66GF25 granules

5. One temperature control zone controlled by one table, and the temperature accuracy can be controlled at ±1℃.

Application of polyamide strip
1. Used for thermal break aluminum window, door, curtain and walls
2. Many customer use thermal break aluminum profile to do big air conditioner to keep heat of cold air, then make use of energy saving

PA66 GF25 Nylon Polyamide Extruder Machine Single Screw For Thermal Barrier Tape

PA66 GF25 Nylon Polyamide Extruder Machine Single Screw For Thermal Barrier TapePA66 GF25 Nylon Polyamide Extruder Machine Single Screw For Thermal Barrier Tape

Our advantage

The extrusion process also offers an excellent surface finish to parts and gives considerable freedom to form in the design process. Extrusion processes are similar to drawing, which uses the tensile strength of the material to pull it through the die. The drawing process is used to produce wire, bars, tubes and profiles.

PA66 GF25 Nylon Polyamide Extruder Machine Single Screw For Thermal Barrier Tape

Our Service

One to one consulting service

Experienced senior engineer to discuss technical data, designed drawing

Perfect arrangement of sea or air transport

Overseas aftersales service

Professional engineers team

Welcomed to visit the factory at any time

Choosing Polywell means choosing the certainty of a reliable partner, able to team up and offer daily support. We are where you need us, whenever you need us.

PA66 GF25 Nylon Polyamide Extruder Machine Single Screw For Thermal Barrier Tape

Production Time

30-38 working days after receiving the deposit

Payment

50% T/T before production, 50%T/T before shipment

Our Factory

PA66 GF25 Nylon Polyamide Extruder Machine Single Screw For Thermal Barrier Tape

Please feel free to contact us if you have any questions.
Camille

E-mail: camille@szpolywell.cn
Tel:86-13584481777
